APC Easy BVX 700VA UPS

The APC Easy UPS BVX 700VA is a battery backup system designed to protect your electronics from power surges and outages. Here's a quick overview:

• Power protection: Provides temporary battery power during outages, allowing you to save your work and safely shut down electronics.
• Surge protection: Safeguards your devices from damaging voltage spikes.
• Compact design: Takes up minimal space, making it suitable for home offices or small workspaces.
• Ideal for: Basic electronics like computers, routers, and peripherals.
• Output power: 360 Watts / 700VA (enough to power essential devices for a limited time during a power outage).

Overall, the APC Easy UPS BVX 700VA is a user-friendly and affordable solution for safeguarding your electronics from common power problems.

Uninterruptible Power Supply (UPS) Specifications

Overview:

• Product Type: Uninterruptible Power Supply (UPS)
• Lead Time: Usually in Stock

Power Capacity:

• Run Time for Load: 360 W (Min-max: 36-360 W)
• Max. Capacity Used: 100%
• Rated Power:
  • In Watts: 360 W
  • In VA: 700 VA
• UPS Type: Line Interactive

Electrical Input:

• Main Input Voltage: 230 V AC 1 phase
• Input Connection Type: IEC 60320 C14
• Network Frequency: 50/60 Hz +/- 5 Hz auto-sensing.
• Input Voltage Limits: 170...280 V 230 V AC
• Cos Phi: 0.51

Electrical Output:

• Main Output Voltage: 230 V AC 1 phase
• Output Frequency: 50/60 Hz +/- 1 Hz sync to mains
• Wave Type: Stepped approximation to a sinewave
• Maximum Configurable Power:
  • In Watts: 360 W
  • In VA: 700 VA
• Output Connection Type: 2 universal
• Transfer Time: 6 ms typical, 10 ms maximum.

Battery:

• Type: Lead-acid battery
• Voltage: 12 V
• Capacity: 7.0 Ah
• Recharge Time: 8 hours
• Battery Life: 2-3 years
• Replacement Battery: APCRBC110

Runtime:

• Max Runtime: 120 min
• Full Load Runtime (360 W): 1 second
• Half Load Runtime (180 W): 6 minutes

Physical Characteristics:

• Color: Black
• Dimensions (HxWxD): 13.8 cm x 9.8 cm x 31 cm
• Net Weight: 4.2 kg
• Mounting Support: Floor
• Mounting Mode: Not rack-mountable
• Mounting Preference: No preference
• Cable Length: 1.22 m
• Number of Cables: 1

Environmental:

• Operating Temperature: 0…40 °C
• Storage Temperature: -15…40 °C
• Operating Relative Humidity: 0…95% non-condensing
• Storage Relative Humidity: 0…95% non-condensing
• Operating Altitude: 0...3000 m
• Storage Altitude: 0…3000 m
• Acoustic Level: 40 dBA
• IP Degree of Protection: IP20

Compliance and Certifications:

• Product Certifications: CE, CB
• Standards:
  • EN/IEC 62040-1:2019/A11:2021
  • EN/IEC 62040-2:2006/AC:2006
  • EN/IEC 62040-2:2018
• Equipment Protection Policy: Lifetime, 50000 euros

Surge Protection and Filtering:

• Surge Energy Rate: 273 J

Packaging:

• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package Dimensions (HxWxL): 22.2 cm x 34.6 cm x 14.2 cm
• Package Weight: 4.5 kg
• SCC14: 10731304417610
